ARRMA ARA-3763 Machined Shock Piston 8x1.4mm

These ARRMA machined shock pistons come in a flat profile with 8x1.4mm holes — precision damping hardware for the Talion 6S EXB's big-bore shocks. The piston is the heart of the damper: its hole count and size determine exactly how fast oil moves past it, which is the damping rate itself.

Machining, rather than molding, delivers pistons that are perfectly flat and consistent — no flash, no warp — so both shocks in a pair damp identically and the truck stays predictable. The flat profile gives symmetric compression and rebound behavior.

The larger 1.4mm holes flow more oil than the 8x1.1mm version (ARA-3762), producing lighter damping — the choice for rough terrain and lower speeds where the suspension needs to move more freely.

Fitment is the ARRMA Talion 6S EXB shock line — confirm against your exploded parts diagram. The package includes two machined flat pistons, 8x1.4mm.
