Description

The Powerhobby 55MG is a compact analog sub-micro servo designed for RC airplanes, helicopters, and other lightweight applications with limited mounting space.

Its precision metal gear train and brushed DC motor provide dependable operation in a lightweight 11g package. At 6.0V, the servo delivers up to 27.77 oz-in of torque with a transit speed of 0.11 second per 60 degrees.

The compact 23 × 12.1 × 21.4mm dimensions make it a practical and economical servo option for compatible small RC models.

Features

• High-performance analog sub-micro servo
• Precision metal gear train
• High-quality brushed DC motor
• Compact and lightweight construction
• 4.8V–6.0V operating range
• Up to 27.77 oz-in of torque
• JR-style connector
• Designed for compatible RC airplanes and helicopters

Includes

• 1 Powerhobby 55MG Analog Sub-Micro Servo

Specifications

• SKU: PH55MG
• UPC: 741030688836
• Servo Type: Analog Sub-Micro Servo
• Operating Voltage: 4.8V–6.0V
• Speed at 4.8V: 0.12 sec/60°
• Speed at 6.0V: 0.11 sec/60°
• Torque at 4.8V: 1.6 kg-cm / 22.22 oz-in
• Torque at 6.0V: 2.0 kg-cm / 27.77 oz-in
• Motor Type: Brushed DC
• Gear Material: Metal
• Dimensions: 23 × 12.1 × 21.4mm
• Dimensions in Inches: 0.90 × 0.47 × 0.84"
• Weight: 11g
• Connector: JR
• Wire Length: 180mm

Fits

Suitable for compatible applications including:

• RC airplanes
• RC helicopters
• Lightweight fixed-wing aircraft
• Other models accepting a 23 × 12.1 × 21.4mm sub-micro servo

Check the servo dimensions, mounting-hole spacing, output spline, servo-horn compatibility, connector type, receiver voltage, and control-linkage requirements before installation.
